Wall Plate Control Panels

Key Features
- SDCP6 – Sends bi-directional RS232 commands simultaneously to control third party devices.
- SDCP6 – Sends infrared codes simultaneously to control the third-party devices and support infrared code learning function
- SDCP9 – Features 8 programmable buttons plus 1 audio mute button, 3 built-in programmable RS232, 2 RS485 and 2 IR connectors.
- SDCP9 – Each button can be programmed to send RS232, RS485, IR or TCP/IP commands simultaneously to control third party devices
- Units may be programmed through the ETHERNET port, via the Control Software.
- Crystal and backlit buttons with easy user-friendly customizable changeable labels.
- The backlit brightness is controllable.
Overview
SEADA’s Wall Plate Control Panels Program buttons to send TCP/IP and RS232 commands to control projectors, screens and other third-party devices.
The SDCP6 Wallplate Control Panel has (3) built-in programmable RS232 connectors and (2) Infrared (IR) connectors. The Programmable Control Panel can fully control the compatible switches, as well as third-party devices such as matrix switcher, compact scaler switcher, projectors, screens, etc. Use the device for presentations in showrooms, classrooms, and boardrooms.
The SDCP9 is a wallplate control panel with 8 programmable buttons plus 1 audio mute button. It features 3 built-in programmable RS232, 2 RS485 and 2 IR connectors. The programmable control panel can fully control the compatible device via TCP/IP, RS232, RS485 and IR, such as matrix switcher, scaler switcher, projectors, screens, etc. Use the device for presentations in showrooms, classrooms, and boardrooms.
Product Range
SDCP6
SEADA’s SDCP6 Program buttons to send TCP/IP and RS232 commands to control projectors, screens and other third-party devices.
SDCP9
SEADA’s SDCP9 has 8 programmable buttons plus 1 audio mute button, 3 built-in programmable RS232, 2 RS485 and 2 IR connectors.
